A powerful, sturdy 10" sawbench with a sliding table that offers excellent value for money.
- Generous aluminium sliding table 350 x 500mm with eccentric hold down clamp
- Heavy cast iron table & saw trunnions to absorb vibration
- Big table surface for easy and safe working
- Mitre slide included for small parts. T-slots on both sides
- Anodised aluminium self-aligning rip fence with fast double clamping
- Precision rip fence setting by rack & pinion
- Heavy crosscut fence with clear scale telescopes to 1.5m and swivels +/-45°
- Strong flip stop with micro-adjustment
- Powerful 2.2kW (3hp) motor for heavy rips
- TCT saw blade included
Some assembly required.
Make an enquiry about the Ascent Machinery SA250ST Sliding Table Saw
Anodised sliding table
Large ribbed anodised aluminium sliding table running on upper and lower steel bars spread widely for stability. Solid aluminium crosscut fence with eccentric clamp; swivels +/-45°.
Note that the saw guard with dust take-off rises, falls and tilts with the riving knife, meeting NZ safety rules.
Full steel bracing
The full steel base braces much better than the splayed leg system.
Dust take-offs from base and hood - and internally ducted for efficient dust removal. Open toe space enables easy sweeping underneath.
Crosscut fence
Crosscut fence extends to 1.5m. Clear scale for easy reading. Solid steel flip-stop with micro-adjustment.
Precision where you need it
Precision rip fence setting by rack & pinion. This is included but you don't have to fit it. Some people prefer to set the fence by hand.
| Saw blade Ø | 254mm (10") x 25.4mm (1") bore |
|---|---|
| Max. cutting height @ 90º | 75mm |
| Max. cutting height @ 45º | 60mm |
| Rip capacity | 630mm |
| Crosscut capacity | 750mm |
| Saw blade speed | 3000rpm |
| Table size | 900mm wide x 800mm deep |
| Motor | 2.2kW (3hp) with 15amp plug |
| Weight | 200kg |
Specifications are subject to change without notice.
If you're looking for a 250mm/10" saw, below are the specifications for our most popular models.
SA250ST Sliding Table Saw
|
SA250 Sawbench
|
Ascent Machinery SA250STE Sliding Table Saw
|
|
|---|---|---|---|
| Motor | 2.2kW (3hp) with 15amp plug | 2.2kW (3hp) with 15amp plug | 2.2kW (3hp) with 15amp plug |
| Table size | 900mm wide x 800mm deep | 1175 x 800mm | 650mm wide x 800mm deep |
| Saw blade Ø | 254mm (10") x 25.4mm (1") bore | 254mm (10") with 25.4mm (1") bore | 254mm (10") x 25.4mm (1") bore |
| Max. cutting height @ 90º | 75mm | 75mm | 80mm |
| Max. cutting height @ 45º | 60mm | 60mm | 60mm |
| Rip capacity | 630mm | 630mm | 810mm |
| Weight | 200kg | 190kg | 230kg |
For a bigger cut take a look at our SA300 range of 300mm/12" saws.
Download the SA250ST brochure >>
Ascent Machinery is available exclusively from Jacks.
Our warranty policy is second to none, and applies to every machine we sell. We're so proud of this policy that you can read it here on our website. We strongly recommend you compare it with others before you buy elsewhere.
