Heavy and Precise Saw Unit

The complete saw unit is mounted on both sides directly to the machine frame - not suspended from the cast iron table. This provides an incredibly stable platform for the saw unit.

Smooth Sliding Table Movement

The aluminium sliding table glides on two hardened chrome bars, with large “dumbbell” rollers between the base and table for smooth and precise movement.

12 sub-rollers pull the table down onto the base while front and rear brushes sweep the chrome bars clear of dust and chips as the table moves. This system guarantees a light, easy and accurate sliding table movement even under heavy loads.

Rip Fence

The large 1000 x 650 mm cast main table and 430 mm wide sliding table are paired with a strongly ribbed, full-size rip table for enhanced stability and precision. • Rip capacity 1250mm • Convenient push stick holder located directly on the rip fence knuckle

Outrigger Table & Crosscut Fence

The outrigger table is supported by a large 400mm deep telescopic support arm, with 30mm thick pivot brackets and a large axle running the through the pivot point of the arm. Brushes at both ends of the telescopic rail keep the arm clean from dust and wood chips. • Telescopic crosscut fence length 3200mm • 2x Crosscut stops

Overhead Saw Guard

Maximise dust extraction in your workshop with the large overhead saw guard. A narrow guard insert for 90° cuts and a wide guard for mitre cuts are both included.

Enjoy a clear view of the workpiece while the saw area remains fully enclosed.
