The most affordable entry to Cross Laminated Timber (CLT) production, Swiss-made Woodtec vacuum presses are proven worldwide. For more than 10 years companies around the globe have been producing large panels with the Woodtec vacuum press technology, with around 40 machines installed. The advantages are attractive:

Make an enquiry about the Woodtec Fankhauser Vacuum Press

Flexible and space saving

You can make elements with different sizes, shapes & thicknesses, simultaneously. You can process whatever materials your customers want.

In contrast to other pressing methods, the assembly and pressing of the panels are carried out on the same area, which saves half the space of other construction methods.

Low investment and operating cost, and scalable

Thanks to vacuum the material and running costs of a press can be minimised. Also, the production is very energy efficient, and any wear is negligible.

Vacuum press beds can be added to accommodate future growth, utilising the same gluing gantry.

Extraordinarily flat

The atmospheric pressure is only exerted on the panel and never on the press body, which therefore is not distorted and keeps its perfectly flat surface.

Pressing height 300mm, customisable
Pressing width Customisable
Pressing length Customisable
Pressing force to 1 atmosphere (0.09 N/mm²)

Specifications are subject to change without notice.

Vacuum Press
Vacuum Press
TimberPress X300
TimberPress X300
Pressing height 300mm, customisable 70 - 400mm
Pressing length Customisable 6000 - 18000mm
Pressing width Customisable 2400 - 3500mm
Pressing force to 1 atmosphere (0.09 N/mm²) 0.4/0.6/0.8 N/mm²

Woodtech offer vacuum pressing solutions for prefabrication
